利用机器学习套件的条形码扫描 API，您可以读取使用大多数标准条形码格式编码的数据。条形码扫描在设备上进行，不需要网络连接。
条形码是将现实世界中的信息传递到应用的一种便捷方式。具体而言，在使用二维码等 2D 格式时，您可以对结构化数据（例如联系信息或 Wi-Fi 网络凭据）进行编码。由于机器学习套件可以自动识别和解析此数据，因此当用户扫描条形码时，您的应用可以智能地做出响应。
对于不需要自定义界面的用户，我们建议您使用 Google 扫码器。扫码器 API 使用与标准条形码扫描 API 相同的推断模型，但只会返回最集中的条形码，从而提供更快、更一致的体验。Google 扫码器也更安全且无需权限，并且不需要与摄像头相关的实现或权限。
iOS
Android
Google 扫码器
主要功能
- 读取大多数标准格式
- 线性格式：Codabar、Code 39、Code 93、Code 128、EAN-8、EAN-13、ITF、UPC-A、UPC-E
- 2D 格式：Aztec、Data Matrix、PDF417、二维码
- 自动格式检测
- 一次扫描所有支持的条形码格式，而无需指定想要的格式，或者将检测器限制为仅扫描您感兴趣的格式，以提高扫描速度。
- 提取结构化数据
- 系统会自动解析使用某种受支持的 2D 格式存储的结构化数据。支持的信息类型包括网址、联系信息、日历活动、电子邮件地址、电话号码、短信提示、ISBN、Wi-Fi 连接信息、地理位置和 AAMVA 标准驱动程序信息。
- 适用于任何屏幕方向
- 无论条形码的方向如何（正置、倒置或侧置），系统都可以识别并扫描条形码。
- 在设备上运行
- 条形码扫描完全在设备上执行，不需要网络连接。
请注意，此 API 无法识别以下形式的条形码：
- 只包含一个字符的一维条形码
- ITF 格式的条形码少于 6 个字符，并且由于缺少校验和而已知该格式不稳定
- 使用 FNC2、FNC3 或 FNC4 编码的条形码
- 在 ECI 模式下生成的二维码
此 API 每次调用 API 时最多只能识别 10 个条形码。
示例结果
|
| 结果 |
|---|
| 角 |
(49,125)、(172,125)、(172,160)、(49,160) |
| 原始值 |
2404105001722 |
|
|
| 结果 |
|---|
| 角 |
(87,87) (612,87) (612,612) (87,612) |
| 原始值 |
WIFI:S:SB1Guest;P:12345;T:WEP;; |
| Wi-Fi 信息 |
| SSID |
SB1Guest |
| 密码 |
12345 |
| 类型 |
WEP |
|
|
